  • Product Details
Applications
For water supply from wells or reservoirs.
For domestic use, for civil and industrial applications.
For garden use and irigation.
Options on request
Special mechanical seal
Other voltages or frequency 60Hz

Operating conditions
Maximum fluid temperature up to+35℃.
Maximum sand content:0.25%.
Maximum immersion:100m.
Maximum well diameter:6"
Warranty:1 year
According to our generalsales conditions.
Motor and Pump
Rewindable motor
Three-phase:380V-415V/50Hz
Single-phase:220V-240V/50Hz
Equip with start control box or digital auto-control box
NEMA dimension standards
Curve tolerance according to ISO 9906
Model Description




Components

Material

Pump external casing

①AISI 316 SS②AISI 304 SS

Suction lantern

①AISI 316 SS②AISI 304 SS

Diffuser

①AISI 316 SS②AISI 304 SS

Impeller

①AISI 316 SS②AISI 304 SS

Shaft

①AISI 316 SS②AISI 304 SS

Shaft coupling

①AISI 316 SS②AISI 304 SS

Wear ring

Rubber

Motor external casing

AISI 304 SS

Top chock

Cast-iron ASTM NO.30

Bottom support

Cast-iron ASTM NO.30

Mechanical seal

Special seal for deep well(Graphite-ceramic/TC)

Shaft

AISI 303 SS-ASTM 5140
